Stainless Steel Sheet Weight Chart in Kg

2024-04-08

An SS (Stainless Steel) sheet weight chart provides a quick reference for the weights of stainless steel sheets based on their thickness, width, and length.

This information is crucial for engineers, fabricators, and professionals involved in material handling and design, as it aids in making informed decisions based on the weight of the material.

The weight of a stainless steel sheet is typically calculated using the formula:
Weight (kg) = Thickness (mm) * Width (mm) * Length (mm) * Density (kg/m³)

The density value used in the calculation varies slightly depending on the specific grade of stainless steel, but a commonly used value is 7.93 kg/m³ for grades like 304 and 316.

Most SS sheet weight charts provide the weight per square meter (kg/m²) or the total weight for common sheet sizes, such as 2000 x 1000 mm, 2500 x 1250 mm, and 3000 x 1500 mm
This allows users to quickly determine the weight of a specific sheet without performing complex calculations.

It's important to note that these charts typically provide theoretical or approximate weights, as the actual weight may vary slightly due to manufacturing tolerances and variations in material density.

Weight Per Stainless Steel Sheet
Thickness In Mm	Size In Mm			Weight Kg/m2
Thickness In Mm	2000 X 1000	2500 X 1250	3000 X 1500	Weight Kg/m2
0.18	2.88	–	–	1.44
0.20	3.20	–	–	1.60
0.22	3.52	–	–	1.76
0.24	3.84	–	–	1.92
0.27	4.32	–	–	2.16
0.28	4.48	–	–	2.24
0.32	5.12	–	–	2.56
0.38	6.08	–	–	3.04
0.44	7.04	11.00	–	3.52
0.50	8.00	12.50	–	4.00
0.56	8.96	14.00	–	4.48
0.63	10.08	15.75	–	5.04
0.75	12.00	18.75	–	6.00
0.88	14.08	22.00	–	7.04
1.00	16.00	25.00	36.00	8.00
.1.13	18.08	28.25	40.00	9.04
1.25	20.00	31.25	45.00	10.00
1.38	22.03	34.50	50.00	72.00
1.50	24.00	37.50	54.00	12.00
1.75	28.00	43.75	63.00	14.00
2.00	32.00	50.00	72.00	16.00
2.25	36.00	56.25	81.00	18.00
2.50	40.00	62.50	90.00	20.00
2.75	44.00	68.75	99.00	22.00
3.00	48.00	75.00	108.00	24.00
3.25	52.00	81.25	117.00	26.00
3.50	56.00	87.50	126.00	28.00
3.75	60.00	93.75	135.00	30.00
4.00	64.00	100.00	144.00	32.00
4.25	68.00	106.25	153.00	34.00
4.50	72.00	112.50	162.00	36.00
5.00	80.00	125.00	180.00	40.00
5.50	88.00	137.50	198.00	44.00
6.00	96.00	150.00	216.00	48.00
6.50	104.00	162.50	234.00	52.00
7.00	112.00	175.00	252.00	56.00
7.50	120.00	187.50	270.00	60.00
8.00	128.00	200.00	288.00	64.00

Stainless Steel Sheet Weight Chart in Kg

The weight of a stainless steel sheet is typically calculated using the formula: Weight (kg) = Thickness (mm) * Width (mm) * Length (mm) * Density (kg/m³)

The weight of a stainless steel sheet is typically calculated using the formula:
Weight (kg) = Thickness (mm) * Width (mm) * Length (mm) * Density (kg/m³)
